Flap Barrier Turnstile Gate
AG-HX27143002 flap barrier turnstile gate offers you a wide range of integrated access control capabilities to fulfill your security demands. It combines cutting-edge technology in a small form. This product can be utilized both indoors and outdoors as a part of security systems.
Its access control technology allows several authentication methods (card/fingerprint), multiple users, and access rights in addition to individual user preferences.
Also, the turnstile gate has a sturdy, anti-tamper construction that prevents unlawful access. Anti-tailgating technology is also built into the turnstile at the gate, preventing unauthorized users from entering the system. The turnstile gate also has a voice reminder mechanism that warns users when it needs to be triggered.
In addition, the emergency stop and emergency bypass features on the Passage turnstile gate make it possible for emergency personnel to enter the area swiftly and efficiently in the event of a crisis.
This device will enhance any security system because it is the ideal synthesis of control and dependability.
Specification
| Specification |
| Product Size | 1400*300*1000mm |
| Material | SUS 304 stainless steel |
| Thickness | Top:1.5mm+body1.2mm |
| Passage Direction | Single directional/Bi-directional |
| Passage Width | 550mm |
| Sensor | 3 pairs of active infrared intrusion detector |
| Throughput Rate | 30~35p/m |
| Reaction Time | 0.2S |
| Driving Voltage | DC24V 6.25A |
| Working Temperature | ·-20~+70℃ |
| Power Input | AC110~220V±10% |
| Motor | Brushless DC Motor |
| Mechanism | Half Hight Flap Gate Mechanism |
| Back up power | Supercapacitor(12V/3A) |
| Indication | LED direction indication |
| Acoustic Alarm | Buzzer Alarm |
| LED | Triple Color LED |
Functionality
1. Upon activation, this flap barrier gate conducts a fault self-check and, if any issues are discovered, emits a warning siren.
2. The operational way -- accessing mode of the flap gate can be predetermined at the main control panel.
3. It has a feature that prevents pinching. If the turnstile arms come into touch with something as they are about to close, the gate will automatically reopen to protect both individuals and the gate itself.
4.The flap barrier turnstile gate features an audible and visual alarm. The gate's LED is blue when it is in the standby mode, green when someone passes through it, and red when someone tries to enter the gate passage without authorization. The buzzer in the gate beeps to warn individuals of the authorization violation.
5. The gate also has "Anti-Collision" technology, which means that if something slams into it too hard, the driving motor will shut off and try to protect itself from the harm.
6. Data for turnstiles from various passages is synced.
7. The system will immediately cancel the visitor's access permit if they do not leave within the specified period. Users can vary this time by adjusting the "waiting duration," which controls how long the system waits before returning the gate to "waiting for open" status.
8. The turnstile will automatically open and close when the electricity is turned on and off.
9. Various readers, such as fingerprint, RFID, and facial recognition readers, can be linked to the flap barrier gate.
Customization Available
In order to make our gate more appropriate for your projects, we may also change the gate's settings or design to fit various circumstances. Contacting our sales team is always an option.
